AT28LV010-20TI

high-performance, 3-volt only, Electrically Erasable, Program-mable Read-Only Memory, TSSOP32

Rated 5 Rating 5 | reviews | Write a review

Price:: US $5.00~8.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $5.00~8.00

PartNumber:: AT28LV010-20TI

Brand:: ATMEL Corporation - ATMEL | Pack: TSSOP | D/C: 03+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Louise H.'s store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-11-09

From Other Seller

Part Number:AT28LV010-20TI
US $5.00 - 8.00
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT28LV010-20TI is a high-performance 3-volt only Electrically Erasable and Program-mable Read-Only Memory. Its 1 megabit of memory is organized as 131,072 words by 8 bits. Manufactured with Atmel’s advanced nonvolatile CMOS technology, the AT28LV010-20TI offers access times to 200 ns with power dissipation of just 54 mW. When the device is deselected, the CMOS standby current is less than 20 µA.

Parametrics

AT28LV010-20TI absolute maximum ratings: (1)Temperature Under Bias: -55 to +125℃; (2)Storage Temperature: -65 to +150℃; (3)All Input Voltages (including NC Pins) with Respect to Ground: -0.6V to +6.25V; (4)All Output Voltages with Respect to Ground: -0.6V to VCC + 0.6V; (5)Voltage on OE and A9 with Respect to Ground: -0.6V to +13.5V.

Features

AT28LV010-20TI features: (1)Single 3.3V ±10% Supply; (2)Fast Read Access Time–200 ns; (3)Automatic Page Write Operation: Internal Address and Data Latches for 128 Bytes; Internal Control Timer; (4)Fast Write Cycle Time: Page Write Cycle Time – 10 ms Maximum; 1 to 128-Byte Page Write Operation; (5)Low Power Dissipation: 15 mA Active Current; 20 μA CMOS Standby Current; (6)Hardware and Software Data Protection; (7)DATA Polling for End of Write Detection ; (8)High Reliability CMOS Technology: Endurance: 105 Cycles; Data Retention: 10 Years; (9)JEDEC Approved Byte-Wide Pinout; (10)Industrial and Automotive Temperature Ranges ; (11)Green (Pb/Halide-free) Packaging Option.
