Product Summary
The 1SMB5947BT3G is a 3 Watt plastic surface mount zener voltage regulator.
Parametrics
1SMB5947BT3G absolute maximum ratings: (1)Maximum Steady State Power. Dissipation @ TL = 75℃. Measured at Zero Lead Length PD: 3.0W; (2)Derate Above 75℃: 40mW/℃; (3)Thermal Resistance from Junction to Lead RθJL: 25℃/W; (4)Maximum Steady State Power Dissipation@ TA = 25℃ PD: 550mW; (5)Derate Above 25℃: 4.4mW/℃; (6)Thermal Resistance from Junction to Ambient, RθJA: 226℃/W; (7)Operating and Storage Temperature Range TJ, Tstg: -65 to+150℃.
Features
1SMB5947BT3G features: (1)Zener Voltage Range - 3.3 V to 200 V; (2)ESD Rating of Class 3 (>16 kV) per Human Body Model; (3)Flat Handling Surface for Accurate Placement; (4)Package Design for Top Side or Bottom Circuit Board Mounting; (5)AEC-Q101 Qualified and PPAP Capable - SZ1SMB59xxT3G; (6)SZ Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; (7)Pb-Free Packages are Available.
